by Wendy Wallner, DVM
Holter Monitor | Echo | L-Carnitine
Historical Perspectives | The
Minimum Heart Screening
What is boxer cardiomyopathy?
Boxer cardiomyopathy as we know it consists
primarily of an electrical conduction disorder which causes the heart to beat erratically
(to have an arrhythmia) some of the time. If the erratic beats occur infrequently and
singly, the dog will probably not have symptoms of heart disease. If the erratic beats
occur in sequence, weakness, collapse or sudden death may result. These arrhythmias may or
may not be detected by listening to the heart with a stethoscope. Whether or not they are
detected depends on the frequency of the abnormal rhythm. If frequent, they can easily be
heard with a stethoscope. The arrhythmia usually consists of VPCs (ventricular premature
contractions) that are heard as an extra beat or a skipped beat that do not have a
corresponding pulse. To identify these, the listener must therefore have one hand on the
stethoscope holding it to the chest and one hand feeling for a pulse (usually at the
femoral artery on the inside of the hind leg). In the normal functioning heart, there is a
pulse for every beat that is heard. When a VPC occurs, a beat is heard through the
stethoscope (and it sounds like a stutter as it is not in the normal rhythm sequence of
the sinus beats), but there is no pulse to go with it. These VPCs have a characteristic
pattern on an ECG and this is the way they are confirmed. Often this is the first
abnormality noticed in a boxer with cardiomyopathy. Usually the dog is having no symptoms
of heart disease when these are noticed by a veterinarian during a routine exam. If the
frequency of these irregular beats increases, the animal may suffer "fainting"
spells (called syncopal episodes). This happens because these abnormal beats do not pump
the blood effectively (no corresponding pulse) to the vital organs like a normal beat does
and the brain becomes oxygen deprived while the abnormal beats are occurring. Usually when
an animal faints, they are having what is known as a run (several in a row) of VPCs. If
the heart corrects itself, the animal regains consciousness in a matter of seconds to
minutes. If the run of VPCs continues, this is termed ventricular tachycardia and can lead
to the development of ventricular fibrillation that is fatal if the rhythm is not
converted. This ventricular fibrillation (V-fib) is the cause of sudden death in most
boxers with cardiomyopathy. There is no blood being pumped through the body when the
animal is in V-fib. Cardiomyopathy can also be responsible for sudden death associated
with anesthesia. Now, just because a boxer has VPCs does not absolutely mean it has
cardiomyopathy IF there is another disease process at work. I have seen animals with
severe infection or cancer have VPCs that resolved completely once the infection was
cleared or the malignancy removed. If, however, VPCs are seen in an otherwise healthy
boxer, one would have a high index of suspicion for cardiomyopathy because of the
prevalence of the disease in the boxer breed.
Some boxers with cardiomyopathy will enter
another phase of disease where the ventricles of the heart start to dilate. At this time
it is unclear whether this is a progression of the electrical conduction disorder, a
separate disease more like that seen in other large breed dogs, or a subset of boxer CM
that is not necessarily a progression of the previously arrhythmic dogs. With this
condition, the walls of the heart become thin, the heart muscle weakens and these animals
can show symptoms of heart failure such as coughing (from lung congestion) and/or fluid
retention in the abdomen (ascites) depending on which side of the heart is most affected.
In time as the heart becomes very enlarged it begins to be an inefficient pump and dogs so
affected may require numerous medications to keep the heart functioning well enough to
sustain life. Still, most boxers affected with cardiomyopathy will ultimately die of their
arrhythmia, not of congestive heart failure. The only way to definitively make the
diagnosis of cardiomyopathy is to have a veterinary pathologist evaluate tissue samples
from the heart muscle after death.
How is boxer cardiomyopathy diagnosed?
The best way to evaluate a boxer for arrhythmia is to use a 24-hour ECG called a Holter
monitor. While an ECG can pick up arrhythmias if they are very frequent, the Holter is
much better at doing so. It will tell you if your dog has VPCs, whether they are frequent
or infrequent, single or multiple, from a single focus in the heart or from several sites.
Not enough boxers have been studied to know if a small number of VPCs may be normal, but
what is known is that most boxers that go on to die of cardiomyopathy have many VPCs in a
24 hour period (hundreds to thousands) and that they have runs of ventricular tachycardia.
The Holter monitor allows us to identify dogs that may have problems due to these runs of
VPCs. For example, most asymptomatic animals have single VPCs interspersed with their
normal beats throughout the 24-hour period. If a Holter shows many clusters or runs of
VPCs, this means that this animal may be at higher risk for syncope or sudden death and
can affect how the dog is treated (with anti-arrhythmic drugs, for example). Comparing
statistics for ECG and Holter, it becomes evident why the Holter is superior in detecting
subtle arrhythmias. The average 3 minute ECG provides the cardiologist with only 240 beats
compared with 90,000 to 110,000 on the average Holter tape. Studies from human medical
literature claim that individuals with more than 3000 VPCs in 24 hours have a 29% chance
of having a normal random ECG, those with 1000-3000 VPCs in 24-hours have a 50% chance of
having a normal random ECG and those with less than 300 VPCs have almost a 100% chance of
having a normal random ECG. This is why so many affected boxers have normal random ECGs.
ECG data is meaningless unless it is abnormal!
Why not use
Since boxer CM is a disease characterized primarily by arrhythmias, Echo is not the method
of choice to make a diagnosis of CM. An echocardiogram is useful to determine if the heart
is contracting properly. It will also help detect and identify the source of any murmurs
that may have been heard on auscultation with a stethoscope by allowing visualization of
the heart valves and blood flow patterns through those valves. It can be used to rule out
the inherited condition of sub-aortic stenosis (SAS) which is known to affect the boxer
and can also lead to sudden death. It can also show whether or not there is any
enlargement of the heart chambers or any thinning (as seen in dilated cardiomyopathy) or
thickening (as seen in hypertrophic cardiomyopathy) of the heart muscle walls. It is not a
good tool for detecting an arrhythmia, unless the arrhythmia is very frequent. Most boxers
with CM will have normal echocardiograms unless they also have SAS or have the type of CM
(progression, different disease or subset?) that causes dilatation of the ventricles.
What about supplementing with L-Carnitine?
It has been shown that dogs on commercial diets have adequate amounts of L-carnitine in
their plasma and that 80% of dogs with cardiomyopathy that have a deficiency of
L-carnitine in the heart muscle have normal to increased L-carnitine levels in their
blood. Although there has been a correlation between two sibling boxers with dilated
cardiomyopathy and a response to supplementation with the L-carnitine, many more boxers
have shown no improvement with supplemental L-carnitine. The two sibling boxers were found
not to have a deficiency of carnitine in the diet, but most likely had an inability to
utilize the carnitine present in their blood and to transport it into the heart cells
where it must be actively concentrated so that it can be used for fatty acid metabolism,
generation of energy and detoxification of certain metabolic compounds. These dogs most
likely had an inherited defect of the membrane transport of L-carnitine. While
supplementation with L-carnitine improved the contractility of these dogs and caused a
temporary improvement, it did not decrease their arrhythmias. One of these dogs eventually
died due to ventricular arrhythmia, the other due to an apparent sudden onset of Addison's
disease. Both parents were also affected with CM, but died before treatment with
L-carnitine could be evaluated. (Keene, 1991)
This condition was identified and defined by Dr. Neil Harpster back in the late 60s and
early 70s. The first paper was published in 1983 and was the result of examination of 64
boxers over a 15-year period with varying presentations of the condition. He described it
as being quite different from other large and giant breed cardiomyopathies as had been
characterized in the Doberman and Great Dane in that the hearts of the affected boxers
showed an absence of dilitation of the ventricles, the dogs rarely suffered from atrial
fibrillation and the heart muscle showed extensive changes histologically on post mortem
The disease was characterized as a
cardiomyopathy based on the human nomenclature which calls myocardial disorders for which
no specific cause can be found "primary cardiomyopathies." Because the dogs that
Harpster studied were closely related, he proposed an inherited origin for the condition.
In the original group of 64 dogs studied, Dr. Harpster found a slight male predisposition
(57.8%) and an age range of 1-15 years with only 15.6% of the dogs less than 6 years of
age and 25% over the age of 10. The average age at the time of diagnosis was 8.2 years.
(In a 1991 report which added another 48 dogs to the original study, the average age at
diagnosis dropped to 6.9 years.)
Dr. Harpster divided the 64 dogs into 3
categories based on the clinical features of their disease. The first category included
dogs that had no clinical signs of disease. The second group had occasional episodes of
fainting or weakness usually after a stressful event but were otherwise completely normal.
The third group included dogs with signs of heart failure. The most common finding on the
physical exams of all of these dogs was the presence of a cardiac arrhythmia. ECG findings
consistently showed ventricular premature beats (VPCs) occurring singly, in pairs and in
runs and episodes of ventricular tachycardia. The portions of ECG which did not show these
abnormal beats appeared normal.
Of the 64 dogs in the original study, only
18 were presented for necropsy. All of the hearts had extensive and diffusely distributed
changes in the myocardium (heart muscle tissue). The changes included the presence of
cells that are not normally seen in heart muscle, the replacement of muscle tissue by
fibrous tissue (scarring), and infiltration of fat into the muscle tissue. (Harpster,
While Dr. Harpster saw equal numbers of each of the three categories of boxer CM, we now
seem to see more boxers in the first two categories and very few with signs of congestive
heart failure. Dr. Kate Meurs at The Ohio State University, currently the most active
researcher in regard to boxer CM and the recipient of the recent ABC/AKC grant, has placed
that number at probably less than 10%. This may be due to increased awareness of the
condition on the part of boxer owners and veterinarians and an increasing number of
"normal" or at least asymptomatic boxers being critically evaluated for the
presence of arrhythmias.
A few years ago, upon my appointment to the
ABC's Health and Research Committee, I came up with a protocol for heart testing for
boxers. These guidelines were published in the ABC News Bulletin in December of
1996. The recommendations were as follows:
Heart Screening for boxers involved in breeding programs and/or performance events:
Age 1 year: auscultation
by a board certified veterinary cardiologist (If arrhythmia detected - Holter exam; if
murmur detected - Echocardiogram)
Rationale: One year is the accepted time for clearance of sub-aortic stenosis. This
auscultation screening could be performed at the national specialty and at individual
breed club's specialty shows for a nominal fee. Any dogs with murmurs would be referred to
a cardiologist in their area for further workup.
Age 2 years: Holter monitor,
auscultation (Echo if murmur detected)
Rationale: The 2-year check would occur before the animal was used for breeding (at
least extensively) and would be useful in detecting dogs with early arrhythmias before
they are bred. In some dogs, arrhythmias have been detected as early as 12 weeks of age.
Age 5 years: Holter monitor,
auscultation (Echo if murmur detected)
Rationale: By 5 years, many animals would show signs of arrhythmia if they were
going to develop CM, since the arrhythmia often precedes clinical disease by several
The main purpose of these screens was to
develop a database which could be analyzed and related to causes of death in dogs so that
some sort of standardized system of interpreting the holter results could be determined.
Not only would it help to identify and eliminate dogs with SAS from breeding programs, it
would also help identify and eliminate those asymptomatic boxers with very large numbers
of VPCs. It was never intended to eliminate any and all dogs with VPCs from breeding
programs. There simply is not enough information available to use the results in this
manner. If large numbers of boxers are not holtered and followed over time, there never
will be a database large enough to provide meaningful holter results. If this is the case,
we are at the mercy of the only other test that will identify boxer CM - a genetic marker
for the disease. Unfortunately, this type of test can take decades to establish. Since we
know that the hallmark of boxer CM is arrhythmia and that the Holter is the best tool to
detect arrhythmia, it is the only method we currently have to try to evaluate our breeding
stock before they have produced offspring. While there currently are no concrete numbers
to identify normal vs. abnormal dogs, the Holter is still extremely important in
identifying those grossly abnormal dogs with hundreds or thousands of VPCs who are
asymptomatic and would otherwise be unknowingly reproduced. Until many Holtered dogs have
been followed into old age and their medical histories analyzed and causes of death
determined, we will not know the true significance of lower numbers of VPCs. We can,
however, use all information obtained through Holter testing responsibly by slanting a
breeding program toward those boxers that seem less affected.
The above guidelines were also sent to the
Secretary of the ACVIM - Specialty of Cardiology with a request to disseminate the
information to all US boarded cardiologists. This was done by Dr. Rebecca Gompf and
several responses from veterinary cardiologists ensued with offers of assistance. The four
ongoing projects, which have arisen out of that communication, are:
a study of boxer heart specimens from deceased dogs known to have had CM (due to
abnormal holter results); a low cost means of analyzing holter tapes; production of
pamphlets detailing SAS and boxer CM for distribution by ABC; and making low-cost
echocardiograms available at ABC.
Project number 1 is being jointly
conducted by Dr. Kate Meurs (OSU) and Dr. Phil Fox (AMC, NY). Boxer hearts are removed
(according to a protocol) from affected dogs after death and shipped to Ohio State
University where they are subjected to MRI (magnetic resonance imaging). They are then
sent to Dr. Fox who is working with a pathologist known for his interest and expertise in
cardiac pathology to determine the histologic changes, variables and similarities from dog
Project number 2 involves Dr. Luis
Braz-Ruivo's offer to analyze holter tapes from boxers for only $30.00. Dr. Meurs will
also analyze tapes for $35 (or $25 if a pedigree is included) but can no longer ship
monitors away from OSU. Both doctor's offers necessitate clubs or individuals purchasing
their own testing equipment.
In the ABC News Bulletin of June 1997,
there was a recommendation for local boxer clubs to purchase their own Holter monitors for
member (and possibly non-member) use. Through Dr. Braz-Ruivo, contact was established with
a Holter monitor manufacturer and a price reduction in the cost of monitors was offered to
anyone affiliated with boxers. The company was Rozinn and they offered us monitors for a
limited period at a cost of $995 (about $500 below the normal price of a monitor). While
the limited period expired long ago, Rozinn is still honoring their price quote of $995 to
anyone that orders a monitor and mentions the ABC or Dr. Braz-Ruivo. The Georgia Boxer
Club bought a monitor in 1997, and the membership voted to charge members a $25/dog usage
fee. Non-members would pay $50/dog. The cost of supplies to attach the monitor is
approximately $15/dog, which brings the total cost of monitoring one dog to $70 for GBC
members. Unfortunately, only a handful of GBC members have used the monitor to date.
However, this small group has used it on multiple occasions.
Regarding project number 3, Dr.
Braz-Ruivo is currently working on the two pamphlets which will be available for the ABC
to use in whatever manner they wish. The pamphlets will detail in lay terms the conditions
of SAS and Boxer CM.
Project number 4 - Dr. Braz-Ruivo
will also be conducting echocardiograms at the ABC in 1999 for a very reduced cost of $75
for pre-registered dogs and $100 for on-site registered dogs. Anyone who has been referred
for echo but does not have easy access to a cardiologist or has a dog with a murmur of
questionable origin should take advantage of this great service.
